FANUC R1000iA /80H
Robot details
The FANUC R‑1000iA/80H is a high-speed 5-axis industrial robot designed specifically for palletizing, material handling, and high-throughput applications.
As part of the R‑1000 series, this model stands out thanks to its slim and compact design, making it ideal for installation in tight or space-constrained work cells. Despite its reduced footprint, it delivers exceptionally high transfer speeds and acceleration, ensuring excellent cycle times and increased productivity.
With a payload capacity of 80 kg and a reach of 2230 mm, the robot is capable of handling medium-size loads efficiently across a variety of industrial processes.
The 5-axis configuration is optimized for fast pick-and-place and palletizing movements, providing a simplified kinematic structure that enhances speed and reliability compared to standard 6-axis robots in these applications.
The robot is built for durability, featuring IP67 protection on the wrist and J3 arm, allowing operation in harsh environments with dust, moisture, and contaminants.
Powered by the FANUC R‑30iB controller, the system benefits from robust motion control, easy programming, and integration with advanced technologies such as vision systems and force sensing.
It supports both floor-mounted and inverted installation, offering flexibility in system design and layout.
Robot applications
✅ General Specifications
- Robot type: 5-axis articulated robot
- Payload: 80 kg
- Reach: 2230 mm
- Repeatability: up to ±0.03 mm
- Robot weight: approx. 610 kg
- Mounting: Floor / Inverted / Angle
Protection rating:
- Body: IP54–IP56
- Wrist & J3 arm: IP67
✅ Axis Speeds (Motor Speeds)
- J1: 185°/s
- J2: 180°/s
- J3: 180°/s
- J4: 180°/s
- J5: 500°/s
