Robot details

The FANUC R-2000iC/270R with R-30iB Plus controller is a high-performance 6-axis industrial robot designed for heavy-duty rack-mounted automation applications that require maximum payload capacity, extended reach, and superior flexibility. Engineered for demanding industrial environments, this robot combines powerful handling capabilities with FANUC’s proven reliability and advanced motion control technology.

With an impressive payload capacity of 270 kg and an extended reach exceeding 3 meters, the R-2000iC/270R is ideal for heavy spot welding, press-to-press handling, machine tending, material handling, palletizing, and automotive manufacturing operations. Its rack-mounted configuration enables manufacturers to save valuable floor space while maintaining an extremely large and efficient working envelope.

The robot features a robust articulated arm structure optimized for heavy payload tasks and high-speed operation. Thanks to its rigid mechanical design and advanced servo control system, the R-2000iC/270R provides excellent repeatability, smooth motion performance, and reduced cycle times even under intensive production demands.

Integrated with the FANUC R-30iB Plus controller, the system offers enhanced processing performance, improved connectivity, energy-efficient operation, and simplified robot programming. The controller supports advanced FANUC technologies including iRVision, Dual Check Safety, Collision Guard, Zero Downtime diagnostics, force sensing, and intelligent motion optimization systems.

The R-30iB Plus platform also includes the FANUC iPendant Touch interface, allowing operators and programmers to manage the robot through an intuitive touchscreen environment that simplifies maintenance, programming, and troubleshooting tasks.

Widely used in the automotive and heavy manufacturing

Robot applications

• Press tending
• Loading and unloading of parts
• Machining
• Handling of parts

General Specifications

• Robot Type: 6-Axis Industrial Robot
• Model: FANUC R-2000iC/270R
• Controller: FANUC R-30iB Plus
• Payload Capacity: 270 kg
• Maximum Reach: Approx. 3,540 mm
• Repeatability: ±0.05 mm
• Mounting Type: Rack Mount
• Protection Rating:
  • Body: IP54 / Optional IP56
  • Wrist & J3 Arm: IP67
• Robot Weight: Approx. 1,495–1,570 kg
• Structure: Articulated Robot

Axis Motion Range

Axis Speeds (Motor Speeds)

Typical Applications

• Heavy Spot Welding
• Material Handling
• Press-to-Press Transfer
• Machine Tending
• Automotive Manufacturing
• Heavy Assembly
• Palletizing
• CNC Loading & Unloading
• Part Transfer
• Industrial Automation Systems
