Robot details

The FANUC R-2000iC/210WE with R-30iB Plus controller is a heavy-duty 6-axis industrial robot specifically designed for harsh industrial environments and demanding applications that require water and dust protection. Engineered for high reliability and durability, this robot is particularly suited for foundry, cleaning, washing, material handling, and heavy industrial automation processes.

With a payload capacity of 210 kg and a robust articulated structure, the R-2000iC/210WE combines high performance, excellent repeatability, and powerful motion control to deliver reliable operation in aggressive production environments. Its reinforced mechanical construction and protected design ensure long-term durability even under challenging operating conditions involving humidity, dust, or contaminants.

The robot features FANUC’s advanced servo-driven motion system, enabling smooth movement, fast cycle times, and high positioning accuracy. Its compact footprint and optimized arm geometry improve accessibility for handling large components, pallets, tooling systems, and industrial parts in confined automation cells.

Integrated with the FANUC R-30iB Plus controller, the system delivers enhanced robot intelligence, advanced motion processing, improved networking capabilities, and lower energy consumption. The controller supports FANUC smart technologies including iRVision, Dual Check Safety, Collision Guard, Learning Vibration Control, and Zero Downtime predictive maintenance systems.

The FANUC iPendant Touch interface simplifies operation and robot programming through an intuitive touchscreen system that improves usability for operators, programmers, and maintenance technicians. This enables faster integration, easier diagnostics, and improved overall productivity.

The FANUC R-2000iC/210WE is widely used in automotive manufacturing, heavy material handling, industrial washing systems, harsh-environment automation, and robotic transfer applications where durability and high payload handling are essential.

Robot applications

• Press tending
• Loading and unloading of parts
• Machining
• Handling of parts

General Specifications

• Robot Type: 6-Axis Industrial Robot
• Model: FANUC R-2000iC/210WE
• Controller: FANUC R-30iB Plus
• Payload Capacity: 210 kg
• Maximum Reach: Approx. 2,450 mm
• Repeatability: ±0.10 mm
• Mounting Type: Floor Mount
• Protection Rating:
  • Body: High environmental protection for harsh conditions
  • Wrist & J3 Arm: Enhanced sealed structure
• Robot Weight: Approx. 1,180 kg
• Structure: Articulated Robot

Axis Motion Range

[igam.com]

Axis Speeds (Motor Speeds)

Typical Applications

• Heavy Material Handling
• Industrial Washing
• Harsh Environment Automation
• Automotive Manufacturing
• Spot Welding
• Assembly Operations
• Press Handling
• Foundry Applications
• Robotic Transfer Systems
• Factory Automation
