FANUC M900iB /330L
Robot details
The FANUC M-900iB/330L is a high-performance long-arm industrial robot designed for heavy payload applications requiring extended reach, exceptional rigidity, and reliable motion control. Built as part of FANUC’s M-900 heavy-duty robot series, this 6-axis robot is ideal for demanding manufacturing environments where large work envelopes and high payload capacities are essential.
The robot offers a payload capacity of 330 kg combined with an impressive horizontal reach of 3203 mm, making it particularly suitable for large-scale material handling, palletizing, heavy spot welding, and automotive body transfer applications. Its optimized mechanical structure and parallel-link arm design provide outstanding stiffness and precision even when operating with large and heavy workpieces at maximum extension.
The M-900iB/330L is controlled by the advanced FANUC R-30iB Plus controller, a next-generation robotic controller engineered for higher productivity, smarter diagnostics, and simplified operation. The controller features enhanced CPU performance, expanded memory capacity, integrated iHMI functionality, and compatibility with advanced FANUC technologies including iRVision, ROBOGUIDE, Dual Check Safety (DCS), and intelligent motion optimization systems.
Thanks to its compact mechanical design and optimized weight-to-payload ratio, the M-900iB/330L can efficiently operate in confined industrial spaces while still covering large operational areas. The robot supports floor, ceiling, and angle mounting configurations for maximum production layout flexibility.
The robot is also engineered for harsh environments. The wrist and J3 arm feature IP67 protection, while optional Severe Dust and Liquid Protection (SDLP) packages provide increased durability in dusty, humid, or contaminant-heavy industrial environments.
Widely used in automotive manufacturing, heavy fabrication, logistics automation, and industrial assembly, the FANUC M-900iB/330L delivers high-speed operation, long-term reliability, and exceptional precision for handling demanding heavy-duty automation tasks.
Robot applications
General Specifications
| Specification | Value |
|---|---|
| Robot Type | 6-Axis Articulated Robot |
| Payload Capacity | 330 kg |
| Reach | 3203 mm |
| Repeatability | ±0.1 mm |
| Mounting Options | Floor, Ceiling, Angle |
| Controller | FANUC R-30iB Plus |
| Protection Rating | IP67 Wrist & J3 Arm |
| Robot Mass | Approx. 1780 kg |
| Drive System | AC Servo Motors |
Axis Motion Range and Speed
| Axis | Motion Range | Max Speed |
|---|---|---|
| J1 | ±370° | 100°/s |
| J2 | ±151° | 85°/s |
| J3 | ±163.7° | 85°/s |
| J4 | ±720° | 90°/s |
| J5 | ±250° | 85°/s |
| J6 | ±720° | 165°/s |
Main Applications
Heavy Material Handling
Perfect for transferring large metal components, automotive structures, and industrial workpieces.
Heavy Duty Spot Welding
Its rigid construction and long reach make it ideal for automotive spot welding systems and large welding tools.
Palletizing
Designed for complete-layer palletizing and high-capacity logistics operations.
Assembly Operations
Suitable for heavy assembly processes that require precise positioning and repeatability.
Part Transfer
Efficient in large production lines where components must be moved across long distances.
Material Removal and Finishing
Can perform grinding, trimming, deburring, and industrial finishing applications.
