FANUC M2000iA /2300
Robot details
The FANUC M-2000iA/2300 with R-30iB Plus controller is one of the most powerful industrial robots ever developed for ultra heavy material handling applications. Designed for extreme payload operations, this 6-axis robot offers an extraordinary payload capacity of 2300 kg and a maximum reach of 3734 mm, making it ideal for handling complete vehicle bodies, massive castings, steel structures, industrial containers, and oversized manufacturing components.
The M-2000iA/2300 is engineered to replace cranes, gantries, lifters, and multiple conventional robotic systems while maintaining precise motion control and high repeatability. Its ultra-rigid mechanical structure and reinforced wrist design enable stable handling of very large payloads in harsh industrial environments such as automotive manufacturing, foundries, heavy machinery production, shipbuilding, steel processing, and logistics automation.
Equipped with the FANUC R-30iB Plus controller, the robot benefits from advanced servo control, high-speed processing, intelligent diagnostics, predictive maintenance functions, and seamless integration into Industry 4.0 manufacturing systems. The controller supports FANUC technologies including iRVision, ROBOGUIDE, and Dual Check Safety (DCS).
Robot applications
Robot Model: FANUC M-2000iA/2300
Controller: FANUC R-30iB Plus
Robot Type: 6-Axis Ultra Heavy Payload Industrial Robot
Payload Capacity: 2300 kg
Maximum Reach: 3734 mm
Vertical Lifting Stroke: approx. 4600 mm
Repeatability: ±0.3 mm
Mechanical Weight: approx. 11700 kg
Mounting Type: Floor Mounted
Axis Motion Range
J1 Axis: 330°
J2 Axis: 160°
J3 Axis: 165°
J4 Axis: 720°
J5 Axis: 240°
J6 Axis: 720°
Maximum Axis Speeds
J1 Axis Speed: 20°/s
J2 Axis Speed: 14°/s
J3 Axis Speed: 14°/s
J4 Axis Speed: 18°/s
J5 Axis Speed: 18°/s
J6 Axis Speed: 40°/s
