FANUC M2000iA /1200
Robot details
The FANUC M-2000iA/1200 with R-30iB Plus controller is one of the most powerful 6-axis industrial robots in the FANUC heavy-payload range. Engineered for ultra-heavy material handling and large-scale automation processes, this robot delivers a massive payload capacity of 1200 kg and an extended reach of 3734 mm, making it ideal for automotive manufacturing, heavy palletizing, foundry automation, large casting handling, structural assembly, and industrial logistics applications.
The M-2000iA/1200 is specifically designed to replace cranes, lifting systems, and multiple conventional robots by combining extreme lifting capability with high repeatability and precise motion control. Its heavy-duty wrist structure with 1250 mm offset enables the handling of oversized and ultra-heavy components while maintaining exceptional stability and accuracy.
Combined with the FANUC R-30iB Plus controller, the system provides advanced servo processing, intelligent diagnostics, high-speed communication, predictive maintenance functions, and seamless Industry 4.0 integration. The controller supports FANUC iRVision, ROBOGUIDE offline programming, and Dual Check Safety (DCS).
Robot applications
Robot Model: FANUC M-2000iA/1200
Controller: FANUC R-30iB Plus
Robot Type: 6-Axis Ultra Heavy Payload Industrial Robot
Payload Capacity: 1200 kg
Optional Payload Capacity: 1350 kg
Maximum Reach: 3734 mm
Repeatability: ±0.18 mm
Mechanical Weight: 8600 kg
Mounting Type: Floor Mounted
Axis Motion Range
J1 Axis: 330°
J2 Axis: 160°
J3 Axis: 165°
J4 Axis: 720°
J5 Axis: 240°
J6 Axis: 720°
Maximum Axis Speeds
J1 Axis Speed: 45°/s
J2 Axis Speed: 30°/s
J3 Axis Speed: 30°/s
J4 Axis Speed: 50°/s
J5 Axis Speed: 50°/s
J6 Axis Speed: 70°/s
