ABB IRB 7720 560/2.90 LID
Robot details
The ABB IRB 7720‑560/2.90 LID is an ultra‑heavy‑duty 6‑axis industrial robot, specifically designed to handle extreme payloads with maximum rigidity, precision, and long‑term reliability. Equipped with LID (Load Integrated Drive) technology, this robot integrates the main drive directly into the robot base, reducing external components and significantly improving load distribution, motion dynamics, and overall system efficiency.
With an outstanding maximum payload of 560 kg and a reach of 2,900 mm, the IRB 7720‑560/2.90 LID is ideally suited for handling very large and heavy components in the most demanding industrial environments. Typical applications include automotive body framing and BIW handling, press tending, die and mold handling, heavy machine loading, and large structural part manipulation. The reinforced mechanical structure ensures smooth motion, high positional stability, and consistent path accuracy, even under continuous ultra‑heavy‑duty operation.
Powered by the ABB IRC5 controller, the robot fully leverages ABB’s advanced motion technologies such as TrueMove™ and QuickMove™, guaranteeing precise trajectory control, synchronized axis movements, and optimized cycle times despite extremely high payloads. Thanks to the Load Integrated Drive architecture, the IRB 7720‑560/2.90 LID offers higher uptime, simplified installation, reduced maintenance, and a lower total cost of ownership compared to conventional ultra‑heavy robot solutions.
The ABB IRB 7720‑560/2.90 LID represents the ideal solution for manufacturers requiring maximum payload automation with modern drive technology and proven ABB industrial robustness.
Robot applications
- Press tending
- Loading and unloading of parts
- Machining
- Handling of parts
- Polishing
- Arc welding
- Spotwelding
- Palletising
- Measurement
- Laser cutting
- Laser welding Nd-Yag
- Glueing - Adhesive bonding
- Assembly of parts
TECHNICAL DATA – ABB IRB 7720‑560/2.90 LID
- Robot type: 6‑axis articulated ultra‑heavy‑payload industrial robot
- Drive technology: LID – Load Integrated Drive
- Maximum payload: 560 kg
- Maximum reach: 2,900 mm
- Repeatability: ±0.1 mm (typical for ultra‑heavy robots)
- Number of axes: 6
- Robot weight: approx. 5,500–6,000 kg
- Protection rating: IP54 (higher protection available depending on configuration)
- Controller: ABB IRC5
- Motion control: ABB QuickMove™ and TrueMove™ technologies
- Installation options: Floor mounting with reinforced heavy‑duty foundation; compact layout enabled by LID design
TYPICAL APPLICATIONS
- Automotive body framing and BIW handling
- Press tending and large transfer systems
- Die and mold handling
- Heavy machine loading and unloading
- Large structure and chassis manipulation
- Foundry, forging, and metal forming automation
- Ultra heavy‑duty industrial assembly and transfer lines
