ABB IRB 390 FLEX PACKER
Robot details
The ABB IRB 390 FLEXPACKER® 15/1300 is a high‑performance delta robot designed for ultra‑fast pick and place operations with higher payload requirements. As part of ABB’s proven FLEXPACKER® platform and powered by the ABB IRC5 controller, this robot combines exceptional speed, precision, and industrial reliability for demanding packaging and material handling environments.
With a maximum payload of 15 kg and a wide working diameter of 1,300 mm, the IRB 390 FLEXPACKER® 15/1300 is ideal for applications involving larger or heavier products, while maintaining very short cycle times. Its parallel kinematic (delta) architecture enables rapid acceleration, smooth trajectories, and stable performance in continuous 24/7 production.
Designed for overhead (ceiling) mounting, the robot maximizes available floor space and allows full, unobstructed access to conveyors and processing equipment. When combined with ABB PickMaster® software and the IRC5 controller, the IRB 390 supports advanced vision‑guided picking, conveyor tracking, and high‑speed synchronization with modern packaging lines.
The ABB IRB 390 FLEXPACKER® 15/1300 is the ideal solution for manufacturers seeking high‑speed automation with increased payload capacity and proven delta robot performance.
Robot applications
TECHNICAL DATA – ABB IRB 390 FLEXPACKER® 15/1300
- Robot type: Delta robot (parallel kinematics)
- Number of axes: 4 axes
- Maximum payload: 15 kg
- Working diameter: 1,300 mm
- Repeatability: ±0.1 mm
- Robot mounting: Overhead / ceiling mounted
- Protection rating: IP54 (IP67 available depending on version)
- Controller: ABB IRC5
- Software compatibility: ABB PickMaster®, vision systems, conveyor tracking
- Motion performance: Ultra‑high‑speed optimized for heavy pick & place operations
TYPICAL APPLICATIONS
- High‑speed pick and place of heavier products
- Packaging and repackaging
- Food and beverage handling
- Pharmaceutical and medical packaging
- Cosmetics and personal care products
- Sorting and singulation
- Conveyor tracking applications
- Vision‑guided robotic picking
